Small but smart
The small E-Series E540 is easy to install and conceal. Thanks to its smart technology, the camera detects people/vehicles/pets, allows real-time remote communication and colour night vision with floodlights on.
Thanks to the technology on the camera for analysing the shapes of people, vehicles and pets, the E-Series E540 provides accurate detections, significantly reducing false alarms on movements of trivial objects.
With this PTZ camera, you can view your world from any angle and automatically track the moving person/car/pet. Keep an eye on intruders and leave them nowhere to hide.
Please note that it tracks the person/car/pet left and right, but not up and down
Note: It follows people/car/pets from left to right, but not up and down
With 5-megapixel resolution and built-in spotlights, this smart IP camera keeps recording in full colour day and night. And even better: you can optically zoom in to find more details.
This smart IP camera supports both 2.4GHz and 5GHz frequencies to ensure better performance for camera networks. One more choice, many conveniences.
Receive notifications when the E Series E540 detects motion. You can configure when to enable notifications - always or on a specific schedule.
Specificaties:
- Video and audio
- Imaging sensor - 1/2,7" CMOS sensor
- Video resolution - Standard: 2560 x 1920 (5.0 megapixels) at 20 frames/sec
- Lens f=2.8 - 8mm F=1.6, with IR cut
- Zoom - 3x optical zoom
- Video format - H.264
- Field of view - Horizontal: 48°- 90° - Vertical: 37°- 68°
- Pan/Tilt angle - Horizontal: 355° - Vertical: 50°
- Day night - IR cut filter with automatic switching
- Infrared night vision - Up to 12 metres (40ft) (LED: 12 pcs/14mil/850nm)
- Colour night vision Spots- : 4 pcs/2.7W/6500K
- Sound - Two-way audio
- DC Power - DC 12.0 V⎓1 A, <12 W
Coupling - Current - DC power port
- System - Reset button
- Ethernet - One 10M/100Mbps RJ45
- Storage - Micro SD card slot (up to 256GB)
- Sound - Built-in microphone and speaker
Software features - Frame rate - Mainstream: 2 fps - 25 fps (default: 20 fps) - Substream: 4 fps - 15 fps (default: 10 fps)
- Code rate - Mainstream: 1024 Kbps - 8192 Kbps (default: 4096 Kbps) - Substream: 64 Kbps - 512 Kbps (default: 256 Kbps)
- Supported browsers - Internet Explorer, Edge, Chrome, Firefox, Safari
- Supported operating system - PC: Windows, Mac OS; Smartphone: iOS, Android
- Smart alarm clock - Motion detection/person detection/vehicle detection/pet detection
- Recording mode - Motion recording (default); scheduled recording; 24/7 recording
- Protocols and standards - HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, P2P, FTP
- Maximum user access - 20 users (1 administrator account and 19 user accounts); supports up to 12 simultaneous video streams (10
- Work with - Google Assist/Reolink Cloud (available in some countries)
Wifi - Wireless standard - IEEE 802.11a/b/g/n
- Wireless frequency - 2.4GHz/5GHz
- Wireless security - WPA-PSK/WPA2-PSK
Work environment - Temperature - Operating temperature: -10°C~+55°C (14°F~131°F)
- Humidity - Operating humidity: 20% ~ 85%
- Water resistant - √
Dimensions and weight - Dimension - Φ85×118mm
- Weight - 380 grams
