Hikvision's Wireless bridges are designed to create network connectivity using 2 or more antennas, for example for camera applications. The antennas with PoE input and output, are suitable for Point-to-point and point-to-multi-point applications. Each antenna has a convenient Wi-Fi management function for local network, configuration and monitoring via WebUI, with easy installation indicators on the side. Hikvision wireless bridges offer flexible and high-performance solutions for wireless video applications.

For a reliable and stable operation of a camera system, good network equipment is essential. Hikvision has a wide range of switches with a focus on video applications. There are various switches available with a high throughput speed, powerful PoE possibilities and optimization functions for video transmission. Available in managed and unmanaged versions, so that a suitable switch is available for every video application.

The antennas are suitable for wall and pole mounting. For pole mounting a set of plastic ties is included that can be used once. Hose clamps can also be used but must be ordered separately.

Point to Multipoint: This product is suitable for Point to Multipoint. This is not plug & play. A web configuration is required for this. Our advice is to configure and connect the antennas first. And only place the antennas when the connections are working.

Clear line of sight is required for good stable operation: In order to function properly, the antennas must have a clear line of sight to each other. Buildings, trees and other obstacles should be avoided. The antennas have a signal indicator where the quality of the connection can be read directly. The antennas have a signal indicator where the quality of the connection can be read directly. Try to place the antennas in sight of each other so that the indicator gives the highest possible indication

Specifications:

Hardware:

• Interfaces: 1 × PoE RJ–45 (1000 Mbps), 1 × LAN RJ–45 (1000 Mbps)
• Power supply: PoE IN: 802.3at
• Included: Power adapter, antenna
• Ethernet ports: 2 (10/100/1000 Mbps)
• Energy consumption: < 30 W
• External ports: 2 × RJ–45, 1 × Reset
• Indicator lights: Power, LAN, Signal intensity

  Features:


• Encryption: WPA-PSK, WPA/WPA2, hidden SSID
• Management: Web configuration, Syslog, NTP
• Certification: CE, FCC
• Network protocols: UDP, TCP, HTTPS, IPv4, NTP, DHCP
• TDMA: Yes, with improvements

  General:


• Reach: Up to 5 km range at 35° angle
• Temperature: -30 °C to +70 °C
• Humidity: 5%–95%, non-condensing
• Weight: 0.46 kg (gross), 0.307 kg (net)
• Dimensions: 132 × 228 × 91 mm (packaging), 90.8 × 57.8 × 187.8 mm (product)
• Assembly: Pole and wall mounting (including ty-wraps)
