LR2226-24-ET-360-V2, 24x PoE Switch with 8 EPoE ports (360W)

Delivery time 1 - 2 working days

€400,26€330,79 -18% -18%
€330,03€272,75 Incl. VATExcl. VAT

    • American Express
    • Apple Pay
    • Bancontact
    • BLIK
    • Google Pay
    • iDEAL
    • Klarna
    • Maestro
    • Mastercard
    • MobilePay
    • PayPal
    • Union Pay
    • Visa
    • Pay afterwards within 30 days - both private and business

      <p>Pay afterwards within 30 days - both private and business</p>

    B2B Installers order with discount

    • Showroom in Gorinchem
    • The best service and warranty
    • 3500+ customers give us a 4.71 / 5
    • Free remote installation

    Size chart

    Hardware Details
    Power adapter included Yes
    PoE (Power over Ethernet) Yes
    Number of Ethernet ports 8
    Ethernet port speed 10/100 Mbps
    Ethernet uplink speed 10/100/1000 Mbps
    Optical uplink speed 1 Gbps
    Description of port functions Ports 1-8: 8 × RJ-45 10/100 Mbps
    Port 9: 1 × RJ-45 10/100/1000 Mbps
    Port 10: 1 × SFP 1000 Mbps
    Power supply External power supply: 54 VDC, 2.22 A
    Operating Temperature -30 °C to +65 °C
    Operating humidity 10%-90% (RH), non-condensing
    Power Consumption Idle: 3.2 W
    Full load: 120 W
    Performance Details
    Low Low 2
    Management type No
    Smart Managed Switch No
    Switch capacity 8.8 Gbps
    Packet forwarding speed 5.36 Mpps
    Packet buffer size 2.75 Mbit
    Jumbo frame 9216 Byte
    MAC table size 8K Byte
    Communication standard IEEE802.3, IEEE802.3u, IEEE802.3ab/z, IEEE802.3X
    Features Details
    PoE protocol IEEE 802.3af; IEEE 802.3at; Hi-PoE; IEEE 802.3bt
    PoE Power Port 1,5 ≤90 W
    Port 2,3,4,6,7,8 ≤30 W
    Total ≤120 W
    PoE pin assignment 1,2,4,5 (V+), 3,6,7,8 (V-)
    ePoE Yes
    PoE long distance transmission Yes
    General Details
    Static charge protection Air discharge: 8 kV
    Contact discharge: 6 kV
    Protection against lightning Direct current: 4 kV
    Differential: 2 kV
    Net weight 0.6 kg (1.32 lb)
    Gross Weight 1.9 kg (4.18 lb)
    Product dimensions 150 mm × 100 mm × 42 mm (5.91" × 3.94" × 1.65")
    Packaging dimensions 265 mm × 238 mm × 76 mm (10.43" × 9.37" × 2.99")
    Housing material Iron
    Installation DIN rail mounting
    Certifications CE; FCC
