Hikvision ColorVu 3.0 Hybrid offers the freedom to choose or combine: 3 functions in 1 camera. This camera series is suitable both as a day/night camera and for 24/7 colour imaging. The combination of ColorVu technology with IR functionality makes the camera versatile. Thanks to its super aperture and highly light-sensitive sensor, this camera delivers unrivalled image quality, even in low light. Advanced noise reduction and an innovative light compensation function (Auto WDR) ensure a clear and balanced image under all conditions.

With Smart Hybrid Light, the camera automatically switches between lighting modes. In low-light situations, night mode with IR illumination is activated. Upon detection of a person or vehicle, the camera immediately switches to colour mode with white LED backlighting. This optimally highlights the scene, displays objects in colour and creates a deterrent effect for unwanted visitors!

• High-resolution 8MP 4K camera with 25fps
• 24/7 colourful images with enhanced ColorVu3.0 technology
• HikAI-ISP for superior noise reduction and sharper details
• Automatic WDR to prevent overexposure and loss of detail
• Smart hybrid illumination smart switching between night vision with IR and colour vision
• Person and vehicle detection Acusense 2.0 technology for targeted security
• Arrayed Dual-Mic for enhanced sound recording and speech clarity
• Anti-corrosion design (NEMA4X) for robust performance in various conditions
• IP67 rating for water and dust resistance

Specificaties:

• Camera

  • Imaging sensor: 1/1,8" Progressive Scan CMOS
  • Max. Resolution: 3840 × 2160
  • Minimum Exposure:
    • Colour: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
  • Shutter speed: 1 s to 1/100,000 s
  • Day & Night: IR cut filter
  • Angle adjustment:
    • Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°

• Lens

  • Lens Type: Fixed focal length lens, 2.8 mm and 4 mm optional
  • Focal Length & FOV:
    • 2.8 mm, horizontal FOV 108.8°, vertical FOV 56.4°, diagonal FOV 134.3°
    • 4 mm, horizontal FOV 93.3°, vertical FOV 47.2°, diagonal FOV 114.2°
  • Lensbevestiging: M16
  • Aperture Type: Fixed
  • Diafragma: F1.0
  • Depth of Field:
    • 2.8 mm: 3.3 m to ∞
    • 4 mm: 3.8 m to ∞
  • DORI:
    • 2.8 mm: D: 89 m, O: 35 m, R: 17 m, I: 8 m
    • 4 mm: D: 109 m, O: 43 m, R: 21 m, I: 10 m

• Verlichter

  • Type of Supplementary Light: White light, IR
  • Range Supplementary Light: Up to 30 m
  • Slim Supplementary Light: Yes
  • IR Wavelength: 850 nm

• Video

  • Hoofdstroom
    • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
    • 60 Hz: 30 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • Substream
    • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
    • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
  • Third Stream
    • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
    • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
    • Third stream is supported under certain settings
  • Video compression:
    • Hoofdstroom: H.265/H.264/H.264+/H.265+
    • Substream: H.265/H.264/MJPEG
    • Third stream: H.265/H.264
  • Video bitrate: 32 Kbps to 16 Mbps
  • H.264 Type: Baseline Profile, Main Profile, High Profile
  • H.265 Type: Main Profile
  • Bitrate Control: CBR, VBR
  • Scalable Video Coding (SVC): H.264 and H.265 encoding
  • Region of Interest (ROI): 1 fixed area for main stream

• Audio

  • Audio Type: Mono sound
  • Audiobitrate:
    • 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)
  • Audiocompressie: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
  • Audio sampling frequency: 8 kHz/16 kHz/32 kHz/48 kHz
  • Environmental noise filtering: Yes

• Netwerk

  • Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP
  • Simultaneous Live View: Up to 6 channels
  • API: ONVIF (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
  • User/Host: Up to 32 users
  • Security: Password protection, complex password, HTTPS encryption, 802.1X-authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, timeout control settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)
  • Netwerkopslag: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
  .
  • Client: iVMS-4200, Hik-Connect, Hik-Central
  • Web browser: Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+,
    Local service: Chrome 80+, Firefox 80+, Edge 89+

• Beeld

  • Beeldinstellingen: Rotation mode, saturation, brightness, contrast, sharpness, gain, white balance, customisable via client software or web browser
  • Day/Night Change: Day, Night, Auto, Schedule
  • Beeldverbetering: BLC, HLC, 3D DNR, Distortion correction, Defuzzification
  • SNR: ≥ 52 dB
  • Wide Dynamic Range (WDR): 130 dB
  • Beeldstabilisatie: EIS
  • Privacy mask: 4 programmable polygonal privacy masks

• Interface

  • Ethernet interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
  • Onboard Storage: Integrated memory card slot, supports microSD/microSDHC/microSDXC cards, up to 512GB
  • Audio: Integrated Microphone: Array dual-microphone
  • Resetknop: Ja

• Algemeen

  • Current: 12 VDC ± 25%, 0.7 A, max 8.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection,
    PoE: IEEE 802.3af, Class 3, max 11 W
  • Materiaal: Housing: Metal, main body: Metal
  .
  • Dimensions: Ø138.3 mm × 115.4 mm (Ø5,4" × 4,5")
  • Packaging dimensions: 170 mm × 170 mm × 160 mm (6,7" × 6,7" × 6,3")
  • Weight: Approximately 750 g (1.7 lb.)
  • Weight with packaging: Approximately 1140 g (2.5 lb.)
  • Storage conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  .
  • Start-up and Operating Temperatures: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
  .
  • General Functions: Heart rate, mirror, flash log, password reset via e-mail, pixel counter, anti-banding
  • Language: 33 languages
